Oil & Gas Industry
Tank Farm Automation for United utilities, UK is an project which Applied implemented for facilitation of a functioning of a tank farm. The operations of a tank farm is to collect oil from tankers and store into huge storage tanks used oil and dirty oil. The store Oil is then purified and transferred to a clean oil storage tank for re-distribution and tankers collect the same. The entire operation were implemented by Applied using a Rockwell Automation System – Compact Logic PLC over distributed IO and RSView Scada. Flowmeters, Pumps, Ac Drives, Thermocouples, Differential Pressure Sensors, Vacuum transducers, Pneumatic activated vales with feedback were integral part of this project.
Oil Regeneration RIG Automation, Redragon Canada is a project for automation of a Regeneration process plant on a 60Ft Mobile RIG. The RIG consisted of monitoring and control of about 590 IO including 220 Analogue IO’s besides AC Drives , heater controls. This process also had Flowmeters, Pressure sensors, Vacuum Sensors and was implemented using Rockwell Control Logix on distributed Device network concepts with a Touch Panel IPC as a HMI.
Tank Farm Automation
Automation Panel for Insulating Oil Regeneration
Automation Panel for Insulating Oil Regeneration_TORS2000
Automation Panel for Insulating Oil Regeneration_TORS6000
Automation Panel for Insulating Oil Regeneration_TORS4000
Automation Panel for Insulating Oil Regeneration_PCB1000
